HORIZON™ L-810 LED Transfer Relay Module
45-1018-001
The Hughey & Phillips HORIZON L-810 Transfer Relay Module is used with the HORIZON L-810 LED Double Obstruction Light. The Transfer Relay assembly will provide operation of one LED module when power is applied. Upon failure of Primary LED, transfer to second LED will occur. A dry contact alarm point is provided to notify of failure of primary lamp.
- Input Voltage: 120/240VAC, 50/60Hz
- Material: PVC/PPO Thermoplastic
- Gasket: Foam In Place
- Enclosure Rating: NEMA 4
- Dimensions: 6” x 6” x 6” (152mm x 152mm x 152mm) (H x W x D)
- Mounting Feet: Four (4) 0.20” Thru-hole tabs
- Mounting Dimensions: 3.42” x 6.74” (87mm x 171mm)
